[Max for Live]Dillon Bastan Nirvana v1.0.0（251MB）

P2P | 24 May 2025 | 251 MB

Nirvana（Max for Live 装置）是一个反馈装置，可以是复音乐器或效果器。但它的作用远不止反馈！它模拟了面包板电路和 2D 空间或素材，用于添加麦克风/扬声器和声源以进行反馈和各种音频放荡！创建乐器和 FX，例如电路弯曲、房间或材料上的反馈、合成/效果的独特/实验形式、空间/材料共振和混响、多普勒效果/合成、各种标准音频效果/合成等等！当然，这是一个噪音/环境/实验音乐的幻想世界，但也可以用于各种流派，因为你可以用它来制作完全降级和非常美妙的声音！Nirvana 是一个声音沙盒，使用它是无限的！

随附：

设备，用户手册，100 个预设，3 个采样

信息版本：

适用于 Live 10 及更高版本！

特征：

复音乐器，最多 6 个声部，每个声部 2 个系统（声源），具有 3 种系统声源模式
空间声源模式：

房间中每个对象最多 4 个的房间的 2D 模拟：麦克风、扬声器和音频源
Microhpones 可以对其应用 FX：滤波器、谐振器、弦乐模型
麦克风指向扬声器时的反馈 它们将音频馈送到
音频源包括：基本振荡器、采样器、外部路由音频和来自其他系统
的声音 用于定位和旋转对象的
2D 接口多普勒效应和音量衰减 根据房间的位置和大小
应用于房间中的所有对象 能够为每个麦克风、扬声器和整个
空间从多个 IR 模型中进行选择 房间的各种功能和其他设置，例如更改大小、添加预延迟、复制对象等
一个可以在整个空间中移动/旋转的听者对象（猫头），如果需要，🙂
还可以喵喵
材质来源模式：

包含与空间模式相同的所有功能，但有一些区别：
模拟具有各种材料（木材、金属等）的 2D 材料平面 IR 文件可供选择
允许材料的
共振/激发/反馈 您可以倾斜它们以模拟在表面上倾斜它们以获得不同的音调
电路源模式：

电路试验板的 2D 模拟，房间内每个对象最多 4 个：音频源、效果和数学运算符
试验板的列连接（求和），允许疯狂的调制！
跳线可以连接起来，以获得狂野的反馈
对象可以动态地调制它们在电路上的位置，在整个语音
中创建新的电路 对象接受输入和输出，允许各种 cv 和调制
音频源和效果选项与空间模式中可用的选项相匹配，但 FX 选项包括延迟线
数学运算符包括： +、-、x、/、pow、clip、tanh、sin、abs 和、插值
每个系统还包括：

振幅 ADSR 包络
基本滤波器
平移和增益
与其他系统的
交叉反馈 调制系统，可应用于许多参数。2 个 LFO、一个包络和一个随机喷雾值
能够使用 MIDI 音符音高控制各种参数：调音、滤波器截止、房间/素材区域、延迟时间和偏移对象位置
能够播放 MIDI 音符或不断
使用设备 对象自动化循环，允许录制和循环自动化以移动空间中对象的位置， material 或 circuit。每个声部都有一个 Looper，因此它就像一个复杂的 LFO
缩放选项，用于显示
单独的装置版本，仅用作效果器，或仅使用其中一种源模式

要安装和使用预设：

按照设备下载中的自述文件进行作！注意：这需要安装 ableton 的 Convolution Reverb Pack：https://www.ableton.com/en/packs/convolution-reverb/

Nirvana (a Max for Live device) is a feedback device that can be a polyphonic instrument or effect. But it can do so much more than feedback! It has simulations of a breadboard circuit and a 2D space or material for adding mics/speakers and sound sources for feedback and all kinds of audio debauchery! Create instruments and FX such as circuit bending, feedbacks in rooms or on materials, unique/experimental forms of synthesis/fx, space/material resonance and reverb, doppler fx/synthesis, all kinds of standard audio fx/synthesis, and so much more! Of course it is a fantasy world for noise/ambient/experimental music, but can also be used for all kinds of genres as you can make both utterly degraded as well as very beautiful sounds with it! Nirvana is a sandbox for sound and the sky’s the limit with using it!

Comes with:

The device, user manual, 100 presets, 3 samples

Version Info:

Works with Live 10 and up!

Features:

Polyphonic instrument with up to 6 voice, 2 systems (sound sources) per voice with 3 system source modes
Space Source Mode:

2D simulation of a room with up to 4 of each object in the room: microphones, speakers, and audio sources
Microhpones can have FX applied to them: filter, resonator, string model
Microphones feedback when pointed at speakers they feed audio to
Audio sources include: basic oscillators, sampler, external routed audio, and sound from the other system
2D interface for positioning and rotating objects
Doppler effect and volume attenuation applied to all objects in the room based on their positions and size of the room
Ability to slect from many IR models for each microphone, speaker and the space overall
Various functions and other settings of the room such as changing the size, adding a pre-delay, duplicating objects, etc
A listener object (cat head) that can move/rotate throughout the space and also Meow if desired 🙂
Material Source Mode:

Contains allt he same features as Space mode with some differences:
Simulates a 2D material plane with various material (wood, metal, etc) IR files to select from
Allows resonation/excitation/feedback of the material
Instead of rotating the mics/speakers you can tilt them to simulated tilting them on a surface to get different tones
Circuit Source Mode:

2D Simulation of a circuit breadboard with up to 4 of each object in the room: audio sources, effects, and math operators
Columns of the breadboard are connected (summed) allowing for insane modulations!
Jumper cables can be made to connect columns for wild feedback
Objects can modulate their positions on the circuit dynamically creating new circuits throughout a voice
Objects take inputs and outputs allowing for various cv and modulations
Audio source and effect options match what are available in Space mode, except FX options include a delay line
Math operators include: +, -, x, /, pow, clip, tanh, sin, abs, and, interpolation
Each system also includes:

An amplitude ADSR envelope
Basic filter
Panning and gain
Crossfeedback with the other system
Modulation system that can apply to many parameters. 2 LFOs, an envelope, and a random spray value
Ability to control various parameters with MIDI note pitches: tunings, filter cutoffs, area of the room/material, delay times, and offsetting object positions
Ability to play with MIDI notes or drone the device constantly
Object automation looping, which allows automations to be recorded and looped for moving the position of the objects in the space, material, or circuit. There is a looper per voice so it works like a complex LFO
Zoom options for the display
Seperate device version for just using as an effect, or just using one of the source modes

To Install And Use Presets:

Follow the Read Me within the device download! NOTE: this requires installing the Convolution Reverb Pack from ableton: https://www.ableton.com/en/packs/convolution-reverb/
